Atlantic Technology IC-6.3-S TriMode In-Ceiling Speaker (Each)
$325.00
Available to order
Available to order — awaiting stock Contact us for lead times.
The requested quantity is not currently in stock. Ordinary backorders may be cancelled before shipment, and standard return terms apply.
We will email a shipment update within one business day of your order, then weekly while you wait and promptly if the estimate changes.
$35 standard shipping per order; free over $1,000. Contiguous U.S. + DC.
Other destinations or special delivery?
Secure checkout
Specialist audio advice
Is this right for your system?Talk to someone who knows the gear.
A closer look
Overview
The Atlantic Technology IC-6.3-S is a TriMode in-ceiling speaker for recessed music or home-theater playback.
At a glance
- One speaker per order quantity of 1.
- Configurable stereo and surround operation from one physical speaker.
- 6.5-inch in-ceiling format.
System and installation
Plan the cutout, mounting depth, ceiling structure and wiring before installation. Match the amplifier connection and any transformer tap to the system design; use the model’s installation drawings for final measurements. Follow the TriMode wiring and switch instructions for the selected operating mode.
Before you order
Confirm current availability and the delivery estimate for your project. Contact Speaker Village with your room or site details, amplifier model and required quantity for help checking the setup.
Technical details and downloads
The IC-6.3/8.3 TriMode™ ceiling mount speaker is a high-quality, versatile solution for your audio needs. With its sleek design, it blends seamlessly into your ceiling, providing an unobtrusive yet powerful audio solution. Equipped with unique dual voice coil woofers and dual 1″ soft-dome pivoting tweeters, it offers a range of configurations for the best audio coverage, whether it's surround sound for your home theater or whole-house music installations.
| IC-6.2 | IC-6.3 | IC-6HT | IC-6SLM | IC-8.2 | IC-8.3 | |
|---|---|---|---|---|---|---|
| Woofer | 6.5" PPM Cone, rubber surround, 1" voice coil, vented pole piece | 6.5" PPM Cone, rubber surround, 1" voice coil, vented pole piece | 6.5" PPM Cone, rubber surround, 1" voice coil, vented pole piece | 6.5" PPM Cone, rubber surround, 1" voice coil, vented pole piece | 8" PPM Cone, rubber surround, 1.25" voice coil, vented pole piece | 8" PPM Cone, rubber surround, 1.25" voice coil, vented pole piece |
| Tweeter | 1" silk dome, wide dispersion, 30 degrees of tilt, ferro-fluid cooled, neodymium magnet | 1" silk dome, wide dispersion, 30 degrees of tilt, ferro-fluid cooled, neodymium magnet | 1" silk dome, wide dispersion, 30 degrees of tilt, ferro-fluid cooled, neodymium magnet | 1" silk dome, wide dispersion, 30 degrees of tilt, ferro-fluid cooled, neodymium magnet | 1" silk dome, wide dispersion, 30 degrees of tilt, ferro-fluid cooled, neodymium magnet | 1" silk dome, wide dispersion, 30 degrees of tilt, ferro-fluid cooled, neodymium magnet |
| Crossover | 3.0 kHz, 12db per octave crossover, PP capacitors, tweeter protection circuit | 2.7 kHz, 12db per octave crossover, PP capacitors, tweeter protection circuit | 2.7 kHz, 12db per octave crossover, PP capacitors, tweeter protection circuit | 3.0 kHz, 12db per octave crossover, PP capacitors, tweeter protection circuit | 2.7 kHz, 12db per octave crossover, PP capacitors, tweeter protection circuit | 2.7 kHz, 12db per octave crossover, PP capacitors, tweeter protection circuit |
| Frequency Response | 48Hz-22Lhz | 48Hz-22Lhz | 45Hz-22Lhz | 50Hz-22Lhz | 45Hz-22Lhz | 45Hz-22Lhz |
| Sensitivity | 88dB | 88dB | 88dB 1W/1M | 92dB | 89dB | 89dB |
| Recommended Amplifier Power | 10-125 Watts RMS | 10-125 watts RMS | 10-125 watts RMS | 10-100 Watts RMS | 10-150 Watts RMS | 10-150 Watts RMS |
| Impedance | 6Ω | 8Ω per channel | 6Ω | 6Ω | 6Ω | 8Ω per channel |
| Cut-Out Size | 8" (202mm) | 8" (202mm) | 8" (202mm) | 8" (202mm) | 9 5 /8″ (244mm) | 9 5 /8″ (244mm) |
| Mounting Depth | 4 1/4" (10.80 cm) | 4" (10.16 cm) | 5 1/4" (13.34 cm) | 2 3/4″ (70mm) | 4 3/4" (12.07 cm) | 4 3/4" (12.07 cm) |
| Weight (single speaker) | 3.5 lbs (1.59kg) | 3.6 lbs, (1.64kg) | 5 lbs (2.27 kg) | 2.6 lbs, (1.2kg) | 5 lbs. (2.27 kg) | 5.25 lbs. (2.39 kg) |
| New Construction Kit (optional) | IC-NC-TLC-6 | IC-NC-TLC-6 | IC-NC-TLC-6 | IC-NC-TLC-6 | IC-NC-TLC-8 | IC-NC-TLC-8 |
| In-ceiling back box (optional) | IC-BOX-6/8 | IC-BOX-6/8 | IC-BOX-6/8 | IC-BOX-6/8 | IC-BOX-6/8 | IC-BOX-6/8 |
| Square Grills (optional) | SQ-GRILLS-6 (9 3/8") | SQ-GRILLS-6 (9 3/8") | SQ-GRILLS-6 (9 3/8") | SQ-GRILLS-6 (9 3/8") | SQ-GRILLS-8 (11″) | SQ-GRILLS-8 (11″) |
| Required Ceiling Thickness | 0.5 – 1″ | 0.5 – 1″ | 0.5 – 1″ | 0.5 – 1″ | 0.5 – 1″ | 0.5 – 1″ |
